Replacement wall tie kit. 50 ties for 20 square metres of an existing wall.

Price excl. VAT
Price incl. VAT
(7 items in stock)

Our replacement wall tie kit has sufficient remedial wall ties to re-tie 20 square metres of brickwork at spacings of 2.5 ties per square metre. When hammered into pilot holes, the grade 304 stainless-steel brick ties screw into brick, block, and concrete. The undercut threads form a reliable fix.

Each brick tie drives into a pilot hole using the impact action of a hammer drill. The tie grips both leaves of a cavity wall. The replacement cavity tie system is easy, quick and cost-effective.

Helical wall ties are suitable for remedial use in all masonry wall types. In addition to using them for wall tie replacement, they are well suited for fixing loose soldier course lintels in place. The SDS setting tool safely confines the tie through the whole insertion process. Make the pilot hole 10 mm longer than the tie so it can be recessed.

The Replacement Wall Tie Kit includes the following.

  • Fifty 9 mm Stainless-steel Helical Wall Ties.
  • One 6 mm x 360 mm SDS Tungsten Carbide Drill Bit. Use a 7 mm bit for tying engineering bricks.
  • One Brick Tie Setting Tool.

This first-class wall tie kit has everything you need to tie 20 square meters of wall. Our helical ties have UKCA and CE Mark Approval to BS EN 845-1: 2013 for use in many types of masonry. The kits are available to buy in various sizes. Select the right tie length to suit the existing cavity wall width.
